Technical data:
| Art.-no. magnet: | 50V42 |
|
Voltage / Frequency: |
42 V |
|
Electricity: |
3.6 Ampere |
| Pole spacing
movable: straight: |
95-190 mm 140 mm |
|
Tear-off force: |
ca. 5,4 kg |
|
Field strength with movable poles: |
Pole distance 190 mm: 20 A/cm
Pole distance 140 mm: 24 A/cm Pole distance 95 mm: 33 A/cm |
|
Field strength with straight poles: |
Pole distance 140 mm: 28 A/cm |
| Power type: | AC |
|
Housing dimensions: |
L215 x D50 x H145 mm |
| Weight: |
incl. movable poles: 3.3 kg incl. straight poles: 3,1 kg |
| Supply line: |
3 m safety cable with safety plug |
|
Norms fulfilled: |
EN 9934-3
ASTM E709 |
|
Scope of delivery: |
|
Complementary
goods
